Automatic Echo Meter
GEOSTAR-112
Designed to register the level buildup curve (level depth, casing pressure, echo graph) according to the user-defined time scheme without the human presence.
Get a quote
Please type-in your phone number and email address for communication purpose.
Automatic echo meter is designed to register the level buildup curve (level depth, casing pressure, echo graph) according to the user-defined time scheme without the human presence.
The device can be operated as:
Tasks to be solved
The device can be operated as:
- automatic echo meter to register the long-time liquid/pressure curves on the user-defined time scheme;
- manual device for high casing pressures;
- remote unit for oilfield automation (supplied with controller and OPC-server).
Tasks to be solved
- Automation of long-term multiple measurements of liquid level, casing pressure in various technological processes.
Сalculations according to API standard
Explosion-proof certified
Features
- Safe muffling and isolation of the discharge when measuring
- Emergency protection against valve opening
- Wide operating temperature range from -40 ° С to +50 ° С
- Possibility to work on wells with low pressure
- Compact and lightweight, easy to install and start up
- Real time clock
- Non-volatile hardware measurement log
- Explosion-proof design
Capabilities
- Ability to input the flexible time scheme of operation
- LogLog, Horner and MDH calculation
- Data preparation in software EDWin
Specification
- Range of liquid level: 8 – 5 000 meters
- Ranges of pressure: 0.2 – 10 MPa (1450 psi) | 0 – 20 MPa (2900 psi)
- Installation type: Wellhead pipe
- Connection thread: NPT 2"
- Level resolution : 0.6 meter
- Pressure measurement full-scale error / Pressure resolution : ± 1,0% / ≤ 0.1 MPa ( 14.5 psi)
- Sample rate: 1 min
- Non-stop operation time: up to 30 days
- Memory capacity (up to 10 sec): 500 (optionally 2000)
- Connection type: Wireless (Bluetooth Low Energy), Cable (optional)
- Interface / Protocol: RS-485 / Modbus RTU
- Weight, less than: 4.0 kg
- Working temperature range: - 40 Cº .. + 50 Cº
Software EDWin
Software EDWin is designed for processing of dynamometer, echo level meter, pressure, power measurements received from GEOSTAR-111/112 device (echo/dynamometer system).
Software can perform the following operations:
1. Transfer registered data from GEOSTAR-111/112 device to computer.
2. Prepare echo/dynamometer/power cards (view/modify the parameters).
3. Print the large variety of reports such as graphic, table, complex, and statistic ones. The powerful report designer helps to create and modify reports.
4. Export to RTF (Office Word), XLS (Office Excel), JPG image, to the transport format (BND2, EDW), DYN-format and to the customer database (on demand).
Visit the EDWin software page for details
Software can perform the following operations:
1. Transfer registered data from GEOSTAR-111/112 device to computer.
2. Prepare echo/dynamometer/power cards (view/modify the parameters).
3. Print the large variety of reports such as graphic, table, complex, and statistic ones. The powerful report designer helps to create and modify reports.
4. Export to RTF (Office Word), XLS (Office Excel), JPG image, to the transport format (BND2, EDW), DYN-format and to the customer database (on demand).
Visit the EDWin software page for details
Certification
Explosion-proof
- The components of the GEOSTAR-111 system comply with the requirements of the technical regulations of the Customs Union TR CU 012/2011 "On the safety of equipment for working in explosive environments".
- Automatic echo meter (GEOSTAR-112): 1Ex ib IIВ T3 (Registration number of the certificate of conformity RU C-RU.MSH06.B.0021)
