Wireless echo meter
GEOSTAR-111.EW

Wireless echo meter GEOSTAR-111.EW is designed to register liquid level depth and measure casing pressure in the annular space of oil&gas wells with wireless method.
GET A QUOTE
PDF
GET A QUOTE
PDF
Wireless echo meter GEOSTAR-111.E is designed to register liquid level depth and measure casing pressure in the annular space of oil&gas wells.
The measurement is based on echoed acoustic signal reflected from the gas-liquid boundary and joints analysis.
Can be used with smartphone to register data.

Tasks to be solved
  • Measurement of static and producing liqud level depth in oil and gas wells
  • Registration level and pressure build-up and drop curves
  • Casing pressure measurement and SBHP/PBHP calculation
  • Pressure Transient Analysis with Log-log, Horner, MDH
  • Gaseous liquid column evaluation
  • Joints-based level calculation and collars data viewer
Сalculations according to API standard
Explosion-proof certified
Features
  • Wireless transfer data from device to the registration unit or smartphone
  • Compact and lightweight
  • Wide range of working temperatures (from -40 °С to +50 °С)
  • Wide range of working pressure (up to 40 MPa) and acquiring liquid level (up to 6000 meters)
  • Wireless data transfer using BLE 5.0 (up to 50 meters air link between sensors and controller)
  • On-site results analysis
Capabilities
  • Measurement of annular gas activity
  • Detailed analysis of echo activity of oil and gas oilwells
  • Data analysis on PC-computer
  • Export data to other systems
Specification
Registration unit BR-21M
Registration unit is designed for recording, processing and storing echo cards and dynamometer cards, for entering and storing parameters of a well, downhole equipment and setup the modes of operations. Controller has a graphical screen, keyboard and rechargeable battery power supply. It is completed with an insulated cover and a built-in heating system for the graphic screen, a spare set of batteries and a charger for them.

Specification:
  • Communications: Wireless (Bluetooth Low Energy), Cable (optional)
  • Interface / Protocol: RS-485 / Modbus RTU
  • Memory (echo cards / levels): 160 pcs.
  • Non-stop operation time: ~30 hours
  • Weight, less than: 1.0 kg
  • Overall dimensions: 210x100x40 mm
Acoustic signal reception unit (ASRU-22/ASRUM-01)
The unit is installed on the wellhead branch pipe and use for record pressure signal and its change in real time.

Specification
  • Installation type: Wellhead pipe
  • Range of liquid level: 8 – 6 000 meters
  • Connection thread: NPT 2"
  • Level resolution : ≤ 1 meter
  • Ranges of pressure: 0 – 10 MPa (1450 psi) | 0 – 20 MPa (2900 psi)| 0 – 40 MPa (5800 psi)
  • Pressure measurement full-scale error / Pressure resolution : ± 1,0% / ≤ 0.1 MPa ( 14.5 psi)
  • Connection type: Wireless (Bluetooth Low Energy)
  • Wireless distance: 50 m
  • Battery capacity: 40 hr
  • Interface / Protocol: RS-485 / Modbus RTU
  • Weight, less than: 2300 g
Valve
The valve is designed to create the acoustic impact for the wells with overpressure.
Acoustic signal generators (UGAS / Gas Guns)
The units are designed to create a sound wave in wells with or without pressure. Includes a rubber crimped pump as standard for measuring levels up to 1000 meters. Additional equipment may include a hand pump, a compressor or a cylinder with compressed air, which allows you to measure levels up to 4500-6000 meters.

Gas Gun types for wells without pressure
  • Rubber Crimped Pump: 0 MPa (0 psi) | 8 – 2 000 meters
  • Manual Pump: 0 – 0,5 MPa (72.5 psi) | 8 – 4 000 meters
  • Air Car Compressor (GIG-103): 0 – 0,8 MPa (116 psi) | 8 – 4 500 meters
  • Gas Cylinder (GIG-104): 0 – 3 MPa (435 psi) | 8 – 6 000 meters
Gas Gun types for wells with pressure
  • Valve assembly*: 0,1 – 40 MPa (14.5 – 5800 psi) | 8 – 4 500 meters
  • *The unit is designed to create a sound wave in wells with excess pressure by short-term pressure relief in the annulus.
Software
The software product EDWin is designed to process and analyze data from sensors (level, load, temperature, pressure, flow rate), prepare and print reports, export / import data.
Software EDWin
Software EDWin is designed for processing of dynamometer, echo level meter, pressure, power measurements received from GEOSTAR-111/112 device (echo/dynamometer system).

Software can perform the following operations:
1. Transfer registered data from GEOSTAR-111/112 device to computer.
2. Prepare echo/dynamometer/power cards (view/modify the parameters).
3. Print the large variety of reports such as graphic, table, complex, and statistic ones. The powerful report designer helps to create and modify reports.
4. Export to RTF (Office Word), XLS (Office Excel), JPG image, to the transport format (BND2, EDW), DYN-format and to the customer database (on demand).

Visit the EDWin software page for details

Certification
Explosion-proof
  • The components of the GEOSTAR-111 system comply with the requirements of the technical regulations of the Customs Union TR CU 012/2011 "On the safety of equipment for working in explosive environments".
  • Acoustic signal registration unit (ASRU-22, ASRUM-01): 1Ex ib IIВ T3 (Registration number of the certificate of conformity RU C-RU.MSH06.B.0021)
  • Spark protection barrier (UVZ-BR-01) for the registration unit: [Ex ib] IIB (Reg. Number of the certificate of conformity RU C-RU.MSH06.B.0021
